Scanner type |
Flatbed; ADF |
Scan Resolution |
Scan Resolution, Optical |
Up to 600 x 600 dpi (color and mono, ADF); Up to 1200 x 1200 dpi (color and mono, flatbed) |
Scan Resolution, Hardware |
Up to 600 x 600 dpi (color and mono, ADF); Up to 1200 x 1200 dpi (color and mono, flatbed) |
Output Resolution Dpi Settings |
75; 150; 200; 240; 300; 400; 500; 600; and 1200 ppi |
Scan Speed |
Scan speed in preview mode |
Up to 8.33 sec, single image scan. (Low resolution preview scan of the whole scanner bed [Flatbed, Entire Scan Area, Color, 75 dpi]) |
Automatic document feeder scan speed |
Up to 30 ppm/60 ipm |
Scan speed OCR (A4) |
OCR A4 (8.5 x 11 in) text page (ADF, 300 dpi, B&W, RTF): 6.37 sec for single image scan. 1.84 sec for single image save; OCR A4 (8.5 x 11 in) text page (Flatbed, 300 dpi, B&W, RTF): 7.8 sec for single image scan. 1.62 sec for single image save. |
Task speed |
OCR A4 (8.5 x 11 in) text page (ADF, 300 dpi, Color, RTF): 6.51 sec for single image scan. 4.45 sec for single image save; A4 (8.5 x 11 in) to e-mail (ADF, 300 dpi, Color, PDF): 6.43 sec for single image scan. 1.56 sec for single image send; OCR A4 (8.5 x 11 in) text page (Flatbed, 300 dpi, Color, RTF): 7.89 sec for single image scan. 4.43 sec for single image save; A4 (8.5 x 11 in) to e-mail (Flatbed, 300 dpi, Color, PDF): 7.89 sec for single image scan. 1.39 sec for single image send. [4 x 6-in is not supported. Slides to file and negative to file are not supported] |
Scan speed footnote number |
[1] Actual speeds may vary depending on scan resolution, connectivity type, computer performance and application software. |
Scanner Specifications |
Duty cycle (daily) |
Recommended daily duty cycle: 4000 pages (ADF), 100 pages (Flatbed) |
Bit Depth |
24-bits external 48-bits internal |
Auto document feeder capacity |
Standard, 50 sheets (75 g/m² paper) |
Scan size, maximum |
216 x 356 mm |
Scan size (ADF), maximum |
216 x 3100 mm |
Scan size ADF (minimum) |
105 x 148 mm |
Scan size, minimum |
25.4 x 25.4 mm |
Scan input modes |
Scan front-panel function for Save as PDF, Save as JPEG, E-mail as PDF, E-mail as JPEG, Send to Cloud, Everyday Scan and Save as Editable Text (OCR). HP Scan in Win OS, HP Easy Scan/ICA in Mac OS and thrid parties applications via TWAIN. |
Scan file format |
For text & images: PDF, JPEG, PNG, BMP, TIFF, Text (.txt), Rich Text (rtf) and Searchable PDF. |
Scanning options (ADF) |
Single pass E-Duplex |
Duplex ADF scanning |
Yes |
Scan technology |
CMOS CIS (Contact Image Sensor) |
Levels of grayscale |
256 |
Color scanning |
Yes |
Multifeed detection |
Yes |
Light source (scanning) |
Light Emitting Diode (LED) |
Scanner advanced features |
Blank page removal; Auto orientation; Auto color detect; Auto crop; Auto exposure; Hole removal; Straighten content; Erase edges; Clean up background; Auto threashold; Color drop out; OCR |
Processor speed |
550 MHz |
Memory |
1 GB |
Connectivity and Communications |
Network ready |
Build-in Ethernet, Wi-Fi 802.11 b/g/n |
Ports |
USB 2.0 or USB 3.0 (SuperSpeed); Built-in Fast Ethernet 10/100/1000Base-TX network port |
Connectivity, standard |
USB 2.0 and USB 3.0 (SuperSpeed); Built-in Fast Ethernet 10/100/1000Base-TX network port |
Twain version |
TWAIN Certified. Version 2.1 |
Control panel |
2.8-in (7.11-cm) Touchscreen, Buttons (Back, Home, Help) |
Power |
Power |
Input Voltage: 100 to 240 VAC |
Power supply type |
External power adapter |
Power Consumption |
6.11 watts (Ready), 1.35 watts (Sleep), 0.05 watts (Auto-Off), 0.05 watts (Off) |
Supported Printing Media |
Media weights, supported, ADF |
45 to 120 g/m² |
Media size (ADF) |
Letter; Legal; Executive; A4; A5; A6; B5; B5 (JIS) |
Media types |
Paper (banner, inkjet, photo, plain), envelopes, labels, cards (greeting, index) |
Environmental |
Operating temperature range |
10 to 35°C |
Storage temperature range |
-40 to 60°C |
Operating humidity range |
15 to 80% RH (non-condensing) |
Non-Operating Humidity Range |
0 to 90% RH (non-condensing) |
Acoustic power emissions |
6.3 B(A) |
Replaceable parts |
Pick-up rollers; pick-up pads |
System Requirements |
Compatible Operating Systems |
Win 7 or higher; Mac: OS X El Capitan 10.11 |
Minimum System Requirements |
Windows 7 or higher; 2 GHz processor, 2 GB RAM, 170 MB hard disk space (driver-only install); USB 2.0, 1024 x 768 SVGA monitor |
Mac compatible |
Yes |
Minimum System Requirements for Macintosh |
Mac OS X El Capitan 10.11; 1 GB available hard disk space, USB or Ethernet port |
Dimensions and Weight |
Dimensions without stand (W x D x H) |
520 x 387 x 145 mm |
Maximum dimensions (W x D x H) |
520 x 387 x 145 mm |
Package dimensions (W x D x H) |
640 x 245 x 486 mm |
Weight |
5.98 kg |
Package weight |
7.9 kg |
Box contents |
What’s in the box |
HP ScanJet Pro 4500 fn1 Network Scanner; Install guide; HP Scan Software & Driver CD; HP Bonus Pack Software CD; Supporting flyers; Cushions; USB cable; Power adaptor; Power cords |
Cable included |
Yes, 1 USB |
Software included |
HP Scanner Device Driver, HP WIA scan driver, HP TWAIN scan driver, HP Scan, HP Scanner Tools Utility, HP Windows Installer, I.R.I.S. Readiris Pro, I.R.I.S. Cardiris, Nuance PaperPort, ISIS driver, Kofax VRS Pro |
Warranty |
Warranty |
1 Year Limited Warranty (Return to HP/Dealer – Unit Exchange) |
Certification and Compliance |
Safety Approvals and Requirements |
IEC 60950-1:2005 +A1 and all applicable amendments; CSA/UL 60950-1, 2nd edition (2007); EN 60950-1:2006 +A11 +A1 +A12+A2; EAC safety; Canada cUL CoC; China CCC; European Union CE; Kenya PVOC; Kuwait TER; Nigeria SON; Saudi Arabia SASO; South Africa NRCS; Taiwan BSMI; Ukraine safety approval |
Electromagnetic Emission Standard |
Class B Emissions; CISPR 22:2008 (International); European Union EMC Directive 2004/108/EC, EN 55022:2010 (CE mark); China GB9254-2008 (CCC); Taiwan CNS13438:2006 (BSMI); USA CFR47 Part 15, Subpart B (FCC); ICES-003:2012 Issue 5 (Canada); Australia C-tick (includes New Zealand); KN 22 and Korea KCC; EAC EMC Certificate; Ukraine EMC approval; EN 61000-3-2:2014 (harmonics); EN 61000-3-3:2013 (flicker); Immunity CISPR 24:2010, EN 50024:2010 |
ENERGY STAR® certified |
Yes |
Compatibility |
Accessories |
HP ScanJet Pro 4500 fn1 ADF Roller Replacement Kit L2742A |
Services (Care Pack) |
HP 2 years Next busines day Onsite Exch SJ 4500 SVC; HP 3 years Next busines day Exch SJ 4500 SVC; HP 3 years Next busines day Exch SJ 4500 SVC; HP 3 years Next busines day Onsite Exch SJ 4500 SVC; HP 3 years Next busines day Onsite Exch SJ 4500 SVC; HP 3 years Std Exch SJ 4500 SVC; HP 3 years Return SJ 4500 SVC; HP 1 year PW Next busines day Exch SJ 4500 SVC; HP 1 year PW Next busines day Onsite Exch SJ 4500 SVC; HP 1 year PW Std Exch SJ 4500 SVC |
